Handheld Laser Engraving Machine - - Forway 1

Handheld Laser Engraving Machine - - Forway 2

Handheld Laser Engraving Machine - - Forway 3

Handheld Laser Engraving Machine - - Forway 4

Handheld Laser Engraving Machine - - Forway 5

Handheld Laser Engraving Machine - - Forway 6

Handheld Laser Engraving Machine - - Forway 7

Handheld Laser Engraving Machine - - Forway 8

Handheld Laser Engraving Machine - - Forway

Inquiry

Product details of the handheld laser engraving machine

Product Information

The design style of Forway handheld laser engraving machine combines tradition with modern concepts. The product is in compliance with international industry quality standards. The potential applications of this product are exciting.

Product Description

The MZF-B series intelligent laser marking machine belongs to the desktop fiber laser marking equipment. It is a special model specially developed by Mac Laser for the needs of simple, compact, flexible and convenient equipment. The equipment is extremely cost-effective, It adopts high-quality fiber laser source, high-stability galvanometer system, hidden keyboard and mouse design, it can easily meet most common laser marking applications.

Product advantage

05-D3产品优势04

04-D3产品优势

06-D3产品优势05

D3产品优势10

07-D3产品优势06

产品优势01

08-D2产品优势08

Application scenario

应用场景01

04-D3应用场景04 拷贝

09-D3应用场景03

10-D3应用场景08

13-D3应用场景09

14-D3应用场景04

11-D3应用场景08

05-D3应用场景03

Product Parameters

Item	value
Application	Laser Engraving
Applicable Material	Acrylic, Leather, Metal, Paper, Wood
Engraving Area	230*280mm
Laser Type	DIODE
Engraving Speed	0.001mm
Graphic Format Supported	PLT, DXF, BMP
Condition	New
CNC or Not	Yes
Cooling Mode	Air Cooling
Place of Origin	China
Place of Origin	Guangdong
Brand Name	MR.CARVE
*Dimension(LWH)*	467435150mm
Laser Source Brand	other
Laser Head Brand	other
Servo Motor Brand	other
Guiderail Brand	other
Control System Brand	other
Optical Lens Brand	other
Weight (KG)	3.2KG
Key Selling Points	Easy to Operate
Warranty	1 Year
Applicable Industries	Food & Beverage Factory, Home Use, Energy & Mining, Advertising Company
Machinery Test Report	Not Available
Video outgoing-inspection	Not Available
Warranty of core components	1 Year
Mode of Operation	Continuous wave
Configuration	bench-top
Feature	3D

Product Details

15-D3应用便捷04

产品优势02

微信图片_20231220170334

配件

微信图片_20231220165727

微信图片_20231220170347

微信图片_20231220170339

微信图片_20231220170342

Product features

Double tube light power is stronger

Spot compression 8mm cutThe carving area is 23*28cm

Double tube light

more power

Support mobile phone/computer, easyengraving

Independently developedsoftware,the interface is simpleeven novice can quickly master

New upgrade

20W high power, direct engraving stainless stee The D3 uses a high-power laser that can be carved directly on 304/201stainless steel surfaces without the need for a second blackening operation

Double tube light

Spot compression,0.05mm finer The two laser beams are aggregated together, and the laser energyisfocused through the compressed spot technology, the spot is only0.05mm,and the power is strengthened again

Carved area

23x28cm large range engraving D3 adopts XY shaft frame design, stable frame structure, can accommodate more large objects Easy to carve cylindrical, cuboid orlarge objects

360° rotary engraving

Be eclectic and create more possibilities With R3 rotation axis, it can achieve 360° rotation engraving on the cylinderadapting to different diameters and sizes of carvings. Software intelligentinteraction,synchronous engravingwithout deformation

Dual light focusing design

Through the compressed spot technology,the focused laser energyis only0.05mm, andthe power is further enhanced

Different power parameters

Laser head model
Engraving Speed	★★★★★	★★★★	★★★	★★
Cutting Capacity	★★★★★	★★★	★★	★
Production process	Twin-tube Combined Light Focusing	Spot Compression Process	/	/
Machine power	20W	15W	7W	3W
Spot size	0.05mm	0.06mm	0.3mm	>0.3mm
Laser beam	2	1	1	1
Engraving line speed(engraving stainless steel as an example)	7200mm/min	3600mm/min	/	/
Basswood cutting(capping data)	8mm	5mm	3mm	1mm
Solid wood cutting(data capped)	2～3mm	1mm	X	X
Black acrylic(Capped Data)	5mm	2mm	2mm	X
201/304 Stainless Steel	√	√	X	X
Anodized Metal	√	√	X	X
Lacquered metal		√	X	X
Electroplated metal	√	√	X	X
Aluminum	√	√	X	X
Plastic	√	√		√
Bamboo	√	√	√	√
Wood	√	√	√	√
Fabric	√	√	√	√
Kraft paper	√	√	√	√
Bone	√	√		√
Food	√	√	√	√
Leather	√	√	√	√
Rubber	√	√	√	√
Ceramics/Glass	√ (Requires matching color paper engraving)
